ASUS ROG STRIX GAMING 1000W - Gen 5 GOLD Fully Modular AURA Power Supply Unit - White
prev
next
Brand : Asus
Features an Aluminum Case that is coupled to the internal power
transformer, helping to reduce temperatures and noise levels. heatsink
to reduce temperatures and noise levels.
Large ROG heatsinks cover critical components, delivering lower temperatures and noise than reference designs.
Axial-tech fan design features a smaller fan hub that facilitates
longer blades and a barrier ring that increases downward air pressure.
Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
0dB Technology lets you enjoy light gaming in relative silence.
An 80 Plus Gold Certification is the result of Japanese capacitors and other premium components.
ASUS ROG STRIX GAMING 1000W - Gen 5 GOLD Fully Modular AURA Power Supply Unit - White
ROG Strix Gold Aura White Edition
Exude Power
The ROG Strix 1000W Gold Aura White Edition combines premium components, superior cooling and captivating RGB illumination to create a formidable force. With huge ROG heatsinks, a high-efficiency Axial-tech fan, and a striking aluminum finish, it’s a pumped-and-primed PSU powerhouse for your next gaming rig.
COOLING
Aluminum Case
Built to run cool
The ROG Strix 1000W Gold Aura White Edition is encased in a strong, sleek aluminum chassis that also acts as a heatsink for the internal power transformer, further helping to reduce temperatures and minimize noise.
Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For ROG Strix Aura White Edition, we've scaled that design to 135mm so it keeps things cool at low RPMs while producing less noise.
Dual Ball Fan Bearings
2x longer lifespan
The fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
0dB Technology
Quiet intelligence
To reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 60% or below.
ENGINEERING
80 Plus Gold Certification
Heart of gold
Top-end Japanese capacitors ensure efficient operation and have helped the ROG Strix Aura White Edition earn an 80 PLUS Gold certification. The increased efficiency also results in less heat, reducing noise and increasing reliability.
Lambda A+ Certification
Quietly deviant
On average, ROG Strix 1000W Gold Aura White Edition emits less than 20 dB of noise – earning a coveted Cybenetics Lambda A+ certification.
ATX 3.0 Compatible
Step into the future
The latest power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and ROG Strix Aura White Edition steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, readying your build for the next-gen.
EXPERIENCE
Aura Sync Outshine the competition
Addressable RGB lighting is built right in to the ROG Strix 1000W Gold Aura White Edition, so it’s all set to integrate with the Aura Sync illumination ecosystem – adding aesthetic style to raw power.
Specifications
Intel Form Factor
ATX12V
PFC Type
Active PFC
ATX 3.0
Yes
Dimensions
180 x 150 x 86 mm
Efficiency
80Plus Gold
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
22A 22A 83.3A 0.3A 3A
Combined Load
120W 120W 996.6W 3.6W 15W
Total Output
1000W
Cable Connectors
MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 (both PSU & component side)PCI-E 8-pin x 4 SATA x 5 PERIPHERAL x 4
Package Contents
Power Cord x 1 Motherboard Power Cable x 1 (600mm) CPU Cable x 2 (650mm) PCI-E Gen 5 16-pin Cable x 1 (675 mm) PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (675 mm) PCI-E 1-to-1 Cable x 2 (675mm) SATA 1-to-2 Cable x 1 (400+120mm)SATA 1-to-3 Cable x 1 (400+120+120mm) Peripheral 1-to-4 Cable x 1 (400+150+150+150mm) Addressable RGB Cable x 1 (800mm) User Manual x 1
Weight
3.03 kg (single PSU)
AURA SYNC
ARGB
Cybenetics Noise Level Certification
A+
0dB Technology
Supported. The fan shuts off entirely when the PSU is under certain load
