ASUS PRIME B650M-R AMD DDR5 micro-ATX Motherboard - Black

slider_1
slider_1
slider_1
slider_1
KD 36.250
Brand : Asus
Quantity :
Add to Cart

    • Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications

    • AM5 Socket for AMD Ryzen™ Desktop Processors

    • Ultrafast Connectivity: PCIe 4.0, two M.2 slots, Realtek 2.5Gb Ethernet, USB 5Gbps ports, front USB 5Gbps Type-C®

    • Comprehensive Cooling: VRM heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+

    • Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers for RGB LED strips, easily synced with Aura Sync-capable hardware

    • Two-way AI Noise Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences

    ASUS PRIME B650M-R AMD DDR5 micro-ATX Motherboard - Black

    AMD B650 Micro-ATX motherboard, DDR5, PCIe 4.0 support, Realtek 2.5Gb Ethernet, HDMI™, SATA 6 Gbps, front USB 5Gbps Type-C®, BIOS FlashBack™, Two-Way AI Noise Cancelation, Aura Sync.

    ASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen 7000-series processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME B650M-R provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. This platform delivers the power and connectivity that advanced AI PC applications demand.

    FLEXIBILITY

    Comprehensive controls form the foundation of the ASUS PRIME series. The PRIME B650 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.

    CPU Performance Boost

    AMD Precision Boost Overdrive(PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD‘s algorithm can leverage the motherboard’s robust power solution to ramp up performance even higher.

    COOLING

    Prime B650 series are engineered with multiple onboard heatsinks and an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.

    VRM Heatsink and Thermal Pad

    VRM heatsink and thermal pads improve heat transfer from the MOSFETs and chokes for better cooling performance.

    PERFORMANCE

    The PRIME B650 series is built to handle the high core counts and bandwidth demands of AMD processors. ASUS B650 motherboard provides all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible data transfer options.

    DDR5 Performance Enhancement

    Comprehensive memory tuning options are the cornerstone of PRIME motherboards. With the PRIME B650M-R, you can extract all of the potential out of your DDR5 modules, whether they're from an extreme-speed kit or an entry-level set that would otherwise be locked.

    For entry-level modules without EXPO™ memory support, we’ve got you covered.

    For those who want to fly past stock DDR5 speeds, the PRIME B650M-R is primed and ready for enthusiast-grade kits courtesy of vast AMD Extended Profiles for Overclocking (EXPO™) support. Seasoned veterans can further tweak performance via the extensive array of settings in the UEFI.

    Specifications

    • Model : PRIME B650M-R

    CPU

    • AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*

    Chipset

    • AMD B650 Chipset

    Memory

    • 2 x DIMM slots, Max. 96GB, DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 Non-ECC, Un-buffered Memory*

    • Dual Channel Memory Architecture

    • Supports AMD Extended Profiles for Overclocking (EXPO™)

    • OptiMem II

    • * Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function.

    Graphics

    • 1 x HDMI™ port*

    • * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.

    • ** Supports 4K@60Hz as specified in HDMI 2.1.

    Expansion Slots

    • AMD Ryzen™ 9000 & 7000 Series Desktop Processors*

    • 1 x PCIe 4.0 x16 slot (supports x16 mode)

    • AMD Ryzen™ 8000 Series Desktop Processors

    • 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)

    • AMD B650 Chipset

    • 1 x PCIe 4.0 x1 slots

    Storage

    • Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
      AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors

    • M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

    • AMD B650 Chipset

    • M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

    • 4 x SATA 6Gb/s ports

    • * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.

    Ethernet

    • 1 x Realtek 2.5Gb Ethernet

    USB

    • Rear USB (Total 6 ports)

    • 2 x USB 5Gbps ports (2 x Type-A)

    • 4 x USB 2.0 ports (4 x Type-A)

    • Front USB (Total 7 ports)

    • 1 x USB 5Gbps connector (supports USB Type-C®)

    • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

    • 2 x USB 2.0 headers support 4 additional USB 2.0 ports

    Audio

    • Realtek 7.1 Surround Sound High Definition Audio CODEC*

    • - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

    • - Supports up to 24-Bit/192 kHz playback

    • Audio Features

    • - Audio Shielding

    • - Premium audio capacitors

    • - Dedicated audio PCB layers

    • * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

    Back Panel I/O Ports

    • 2 x USB 5Gbps ports (2 x Type-A)

    • 4 x USB 2.0 ports (4 x Type-A)

    • 1 x HDMI™ port

    • 1 x Realtek 2.5Gb Ethernet port

    • 3 x Audio jacks

    • 1 x BIOS FlashBack™ button

    Internal I/O Connectors

    • Fan and Cooling related

    • 1 x 4-pin CPU Fan header

    • 2 x 4-pin Chassis Fan headers

    • Power related

    • 1 x 24-pin Main Power connector

    • 1 x 8-pin +12V Power connector

    • Storage related

    • 2 x M.2 slots (Key M)

    • 4 x SATA 6Gb/s ports

    • USB

    • 1 x USB 5Gbps connector (supports USB Type-C® )

    • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

    • 2 x USB 2.0 headers support 4 additional USB 2.0 ports

    • Miscellaneous

    • 3 x Addressable Gen 2 headers

    • 1 x Clear CMOS header

    • 1 x COM Port header

    • 1 x Front Panel Audio header (AAFP)

    • 1 x S/PDIF Out header

    • 1 x Speaker header

    • 1 x SPI TPM header (14-1pin)

    • 1 x 10-1 pin System Panel header

    Special Features

    • ASUS 5X PROTECTION III

    • - DIGI+ VRM

    • - LANGuard

    • - Overvoltage Protection

    • - Safeslot Core

    • - Stainless-Steel Back I/O

    • ASUS Q-Design

    • - Q-DIMM

    • - Q-LED Core

    • - Q-Slot

    • ASUS Thermal Solution

    • -  VRM heatsink design

    • ASUS EZ DIY

    • - BIOS FlashBack™ button

    • - BIOS FlashBack™ LED

    • Aura Sync

    • - Addressable Gen 2 headers

    Software Features

    • ASUS Exclusive Software

    • Armoury Crate

    • - Aura Creator

    • - Aura Sync

    • - Fan Xpert 2+

    • - Power Saving

    • - Two-Way AI Noise Cancellation

    • AI Suite 3

    • - TurboV EVO

    • - DIGI+ VRM

    • - PC Cleaner

    • ASUS CPU-Z

    • Norton 360 Deluxe (60 Days Free Trial)

    • WinRAR (40 Days Free Trial)

    • UEFI BIOS

    • ASUS EZ DIY

    • - ASUS CrashFree BIOS 3

    • - ASUS EZ Flash 3

    • - ASUS UEFI BIOS EZ Mode

    BIOS

    • 256 Mb Flash ROM, UEFI AMI BIOS

    Manageability

    • WOL by PME, PXE

    Accessories

    • Cables

    • 2 x SATA 6Gb/s cables

    • Miscellaneous

    • 1 x I/O Shield

    • 2 x M.2 Anchors

    • Documentation

    • 1 x Quick start guide

    Operating System

    • Windows® 11, Windows® 10 64-bit

    Form Factor

    • micro-ATX Form Factor

    • 9.3 inch x 8.7 inch ( 23.6 cm x 22.1 cm )
