Gigabyte Z590 AORUS ELITE AX (rev. 1.0) ATX Motherboard

KD 89.000
Brand : Gigabyte
Quantity :

    • Supports 11th and 10th Gen Intel® Core™ Series Processors
    • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
    • Direct 12+1 Phases Digital VRM Solution with 60A DrMOS
    • Shielded Memory Routing for Better Memory Overclocking
    • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
    • Onboard Intel® WiFi 6 802.11ax 2T2R & BT5 with AORUS Antenna
    • AMP-UP Audio with ALC1220 and WIMA Audio Capacitors
    • Fast 2.5GbE LAN with Bandwidth Management
    • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2 with Thermal Guards
    • SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
    • Pre-installed IO Shield for Easy and Quick Installation
    • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
    • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
    • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card


    Gigabyte Z590 AORUS ELITE AX (rev. 1.0) ATX Motherboard

    DIRECT POWER DESIGN

    Z590 AORUS ELITE AX motherboard uses an 12+1 phases digital CPU power design which includes both digital PWM Controller and DrMOS. These 100% digital controller and additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU.

    ADVANCED THERMAL SOLUTION

    Z590 AORUS ELITE AX uses high performance Full Covered thermal design with high coverage MOSFET Heatsinks and thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers and gamers.

    UNPARALLELED PERFORMANCE

    With the best quality components and GIGABYTE R&D design capability, the Z590 AORUS is a true beast among motherboards.

    NEXT GENERATION CONNECTIVITY

    A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590 AORUS ELITE AX provides all next generation network, storage, and WIFI connectivity to keep you up to speed.

    Immersive Gaming ViBes

    Realtek High-End HD Audio Codec

    ALC1220 120dB(A) SNR HD Audio with Smart Headphone Amp automatically detects impedance of your head-worn audio device, preventing issues such as low volume and distortion. With the new VB series audio controller, stream your voice to the world vibrantly with both front/rear microphone SNR up to 110/114dB(A).

    DEFINITIVE AESTHETICS

    Z590 AORUS ELITE AX features RGB FUSION 2.0 and offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique and stylish.

    ULTRA DURABLE

    GIGABYTE is reputable for its product durability and high quality manufacturing process. Needless to say, we use the best components we can find for the Z590 AORUS motherboard and reinforce every slot to make each of them solid and durable.

    New User Interface

    All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.

    My Favorites

    Add constantly used items into the favorite menu for quick access.

    Storage Information

    Show all kinds of storage information including SATA, PCIE and M.2 interface.

    Changelog

    List all changes before saving and exiting bios. Quickly review overall settings modification.

    Intuitive Load Line Curve

    Clearly show each loadline calibration setting in an intuitive curve graph.

    Specifications

    CPU : LGA1200 package:

    • 11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
    • 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors*
    • * Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family.
    • L3 cache varies with CPU
    • (Please refer to "CPU Support List" for more information.)

    Chipset

    • Intel® Z590 Express Chipset

    Memory

    • 11th Generation Intel® Core™ i9/i7/i5 processors:
    • Support for DDR4 5400 (O.C)/ DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
    • 10th Generation Intel® Core™ i9/i7 processors:
    • Support for DDR4 2933/2666/2400/2133 MHz memory modules
    • 10th Generation Intel® Core™ i5/i3 /Pentium®/Celeron® processors:
    • Support for DDR4 2666/2400/2133 MHz memory modules
    • 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

    Dual channel memory architecture

    • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    • Support for Extreme Memory Profile (XMP) memory modules
    • (Please refer "Memory Support List" for more information.)
    Onboard Graphics
    • Integrated Graphics Processor-Intel® HD Graphics support:
    • 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
    • * Support for DisplayPort 1.2 version and HDCP 2.3.
    • (Graphics specifications may vary depending on CPU support.)

    Audio

    • Realtek® ALC1220-VB codec
    • * The back panel line out jack supports DSD audio
    • High Definition Audio
    • 2/4/5.1/7.1-channel
    • Support for S/PDIF Out

    LAN

    • Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
    Wireless Communication module
    • Intel® Wi-Fi 6 AX201:
    • WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
    • BLUETOOTH 5.1
    • Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    • * Actual data rate may vary depending on environment and equipment.

    Expansion Slots

    • 1 x PCI Express x16 slot, running at x16 (PCIEX16)
    • * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    • (The PCIEX16 slot conforms to PCI Express 4.0 standard.)*
    • *Supported by 11th Generation processors only.
    • 1 x PCI Express x16 slot, running at x4 (PCIEX4)
    • 1 x PCI Express x1 slot
    • (PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)

    Multi-Graphics Technology

    • Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

    Storage Interface

    CPU:
    • 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)*
    • *Supported by 11th Generation processors only.
    Chipset:

    • 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2B_SB)
    • 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2P_SB)
    • 6 x SATA 6Gb/s connectors
    • Support for RAID 0, RAID 1, RAID 5, and RAID 10
    • * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
    • Intel® Optane™ Memory Ready

    USB

    Chipset:

    • 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
    • 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    • 2 x USB 3.2 Gen2 Type-A ports (red) on the back panel
    • 5 x USB 3.2 Gen1 ports (3 ports on the back panel, 2 ports available through the internal USB header)

    Chipset+2 USB 2.0 Hub:

    • 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

    Internal I/O Connectors

    • 1 x 24-pin ATX main power connector
    • 1 x 8-pin ATX 12V power connector
    • 1 x 4-pin ATX 12V power connector
    • 1 x CPU fan header
    • 1 x water cooling CPU fan header
    • 3 x system fan headers
    • 1 x system fan/water cooling pump header
    • 2 x addressable LED strip headers
    • 2 x RGB LED strip headers
    • 6 x SATA 6Gb/s connectors
    • 3 x M.2 Socket 3 connectors
    • 1 x front panel header
    • 1 x front panel audio header
    • 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    • 1 x USB 3.2 Gen1 header
    • 2 x USB 2.0/1.1 headers
    • 2 x Thunderbolt™ add-in card connectors
    • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI / GC-TPM2.0 SPI 2.0 module only)
    • 1 x Clear CMOS jumper
    • 1 x Q-Flash Plus button
    • *All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.

    Back Panel Connectors

    • 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
    • 2 x USB 3.2 Gen 2 Type-A ports (red)
    • 3 x USB 3.2 Gen 1 ports
    • 4 x USB 2.0/1.1 ports
    • 2 x SMA antenna connectors (2T2R)
    • 1 x DisplayPort
    • 1 x RJ-45 port
    • 1 x optical S/PDIF Out connector
    • 5 x audio jacks

    I/O Controller

    • iTE® I/O Controller Chip
    • H/W Monitoring
    • Voltage detection
    • Temperature detection
    • Fan speed detection
    • Water cooling flow rate detection
    • Fan fail warning
    • Fan speed control
    • * Whether the fan speed control function is supported will depend on the fan you install.

    BIOS

    • 1 x 256 Mbit flash
    • Use of licensed AMI UEFI BIOS
    • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    Unique Features

    • Support for APP Center
    • * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    • @BIOS
    • EasyTune
    • Fast Boot
    • Game Boost
    • ON/OFF Charge
    • RGB Fusion
    • Smart Backup
    • System Information Viewer
    • Support for Q-Flash Plus
    • Support for Q-Flash
    • Support for Xpress Install

    Bundled Software

    • Norton® Internet Security (OEM version)
    • Realtek® 8125 Gaming LAN Bandwidth Control Utility

    Operating System

    • Support for Windows 10 64-bit

    Form Factor

    • ATX Form Factor; 30.5cm x 24.4cm
    * The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
    * Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
    * All trademarks and logos are the properties of their respective holders.
    * Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
