The new NVIDIA® Ada Lovelace architecture delivers a quantum leap in performance, efficiency, and AI-powered graphics. It has new Streaming Multiprocessors, 3rd generation Ray Tracing Cores, and 4th generation Tensor Cores. It's built on a new custom TSMC 4N process, runs with blazing fast clocks, and features a large L2 cache. It enables fast ray tracing, new ways to create, and much more.
Ada Lovelace architecture
The new NVIDIA® Ada Lovelace architecture delivers a quantum leap in performance, efficiency, and AI-powered graphics.
The Quietest RTX 4080 - TechPowerUp
"PNY has done a fantastic job. Their card is actually the quietest RTX 4080 that I've tested today…I have to say I really like this move by PNY and I would pick their card over the Founders Edition in a heartbeat, for the ultra-low-noise operation and better cooler.”
Double Ball Bearing Fan
Adopts with 3 100mm double ball bearing round fans. Compare to traditional 90mm fans, offer 40% more airflow and gain 55% air pressure. In addition the round fan blade converge the airs to enhance thermal performance.
Thermal Module
Fans 3x 100mm double ball bearing offers 70,000+hours lifespan Giant Heatsink Dense fins greatly increase the heat dissipation area 8x Heatpipes Adopts 2 x Φ=8mm + 6 x Φ=6mm heatpipes to conduct heat to the fin Copper Base Direct contact with GPU to efficiently transfer heat
Stamping Backplate
Metal Backplate Strength the graphics card structure to prevent sag. Aluminum to accelerate heat transformation Air Vents To allow airflow to heat dissipation
VGA Support Kits Included
Anti-Graphics Card sag
Simple to set up and effective
Invisible Design
Optimized Size & Chassis Compatiblity
PNY GeForce RTX4080 compatibles with the main steam ATX full tower chassis in the market by decent size.
VelocityX Overclocking Software
PNY's VelocityX Overclocking Software allows you to monitor critical stats, like Core Clock, Memory Clock, Core Temperature, Fan Speed, Core Voltage, Power Usage, Core Usage, and Memory Usage in real time, generating invaluable intel that you can leverage to further fine-tune and customize your settings to master your system and take your gaming to the next level.
Specifications
Card Dimensions : 331.8 x 136.8 x 71.1mm; 3.5 Slot
Box Dimensions : 405 x 199 x 103mm
Clock Speed : 2205 MHz
Boost Speed : 2550 MHz
Memory Speed (Gbps) : 23 Gbps
Memory Size : 16GB GDDR6X
Memory Interface : 256-bit
Memory Bandwidth(GB/sec) : 763 Gbps
TDP : 320 W
NVLink : Not Supported
Outputs : 3x DisplayPort 1.4, HDMI 2.1
Multi-Screen : Up to 4
Resolution : m7680 x 4320 @120Hz (Digital)
Power Input : One 16-Pin (One 16-pin to Three 8-pin)
Bus Type : PCI-Express 4.0 x16
Note
Accessories: PCIe5 12VHPWR Adapter & VGA Support Kits
